Butt Weld Lateral Tee

The Butt Weld Lateral Tee is a critical component for connecting branch pipes to the main pipeline. Designed with a 45° bevel, this fitting minimizes fluid resistance and improves flow efficiency, making it ideal for high-pressure systems. Its direct welding connection to the main pipe ensures both a strong seal and robust structural integrity. This product is perfect for complex piping networks that require precise angle control and reliable performance under demanding conditions. Whether you're working in industries like oil & gas, chemical processing, or water treatment, the Butt Weld Lateral Tee is engineered to deliver optimal flow management and long-term durability. With its proven strength and efficiency, it provides a cost-effective solution for enhancing the performance of your pipeline system. Choose the Butt Weld Lateral Tee to ensure a seamless, reliable, and efficient connection in your piping infrastructure.

SPECIFICATIONS
product details
Function • 45° bevel branch connection
• Reduces fluid resistance by 30-40%
• Optimizes flow efficiency
• High-pressure rated (ASME B16.9 Class 3000#)
Production Process 1. Material prep (ASTM-certified raw materials)
2. Hot press/forging forming
3. Automated orbital welding
4. Post-weld heat treatment
5. 100% RT/UT inspection
Applications • Refinery piping systems
• Natural gas distribution
• Chemical process units
• Power plant steam lines
Size Range DN15 (½") - DN3800 (150")
• Standard: ASME B16.9/GB12459
• Large-diameter: MSS SP-75 compliant
Materials • Carbon Steel: A234 WPB/WPC
• Stainless: 304/316L (ASTM A403)
• Alloy Steel: 15CrMoV (P11/P22)
Pressure Rating Sch5s-Sch160
• PN6-PN420 (EN)
• Class 150-2500 (ASME)
